Tehnička specifikacija

Intelligent protection
- Never lose your data again due to a power outage. NemoLCD is your shield to protect printers, faxes, PCs and all the devices in your workstation. With smart interface for power management, you will leave nothing to chance.

Line Interactive Technology
- Security and flexibility! The UPSs of the Elsist Line Interactive range guarantee a stabilized and always reliable power supply at low cost. Thanks to a discreet and attractive design and a simplified installation system, they are the most suitable solution for small offices and home applications.
AVR circuit operation with additional battery regulates mains variations to ensure high power quality at all times.

Innovative energy
- At Elsist we believe that environmental protection is not an abstract concept, but a concrete need to be found in every product. This is why we propose a clean energy model and focus on the high efficiency of UPS.
Power consumption is minimized, and with a regulated power supply, you can extend the life and efficiency of all your devices.

360 Support
- Need a hand and need it quickly? Call us now! We offer a complete service of assistance and preventive maintenance throughout the national territory. Thanks to permanent monitoring, our technicians are always active for a 24-hour monitoring service.
And if an intervention is required on site, do not worry: our specialized staff will be at your place within 24 hours of the call. Seeing is believing!

A domestic ally
- Protect critical loads in your home and in small offices or shops with Elsist UPS: PCs, modems, faxes, set-top boxes, but also POS systems and surveillance. For all small companies with great needs for stable current.

Specifications
INPUT
- Input Voltage 220-230-240Vac
- Input voltage range 162-290Vac
- Frequency 50/60Hz (auto selection
- Output Voltage 230Vca
- Voltage tolerance ? 10%
- Frequency 50/60Hz (following input frequency)
- Power: 1600VA
- Active Power: 600W
- Switching time: 2-6 mS tpc
- IEC outlet: 2
- Schuko outlet: 2

NOISE FILTERING
- Modem / T port (10BaseT/100baseT): RJ11/RJ45 (rete compatibile)

BATTERY
- Typ. Autonomy time: 10 min
- Battery capacity: 2x7Ah
- Type: Maintenance-free, sealed lead-acid
- Recharging time: 6-8 hr at 90% after a deep discharge

PROTECTION
- Overvoltage/Undervoltage: Switch to “Battery mode”
- Overload/Shortcircuit: Fuse and Electronic threshold (both on “Mains mode” and on “Battery mode”).

MECHANICAL CHARACTERISTICS
- Dimensions (WxDxH) mm: 149x350x162
- Weight (Kg): 8,4

ENVIROMENT
- Ambient: Temperature 0-40°C ,Humidity 0-90% without condensa tion, altitude max. 3000 mt.
- Audible noise: < 40dbA (measured at 1mt.) both on “Mains mode” and on “Battery mode”.

STANDARD
- IEC/EN62040-1 IEC/EN62040-2 IEC/EN62040-3 IEC/EN60950-1
